Industrial 240x128 LCD Module With ZEBRA Connection Monochrome LCD Panel With STN FTTN Display
OEM & Custom ZEBRA Connection Monochrome LCD Panel With STN FTTN Display
1. Product Specifications and Features
(1) High-Resolution Sharp Visuals:
240×128 dot resolution with STN (Blue) transflective negative display and FTTN semi-transparent gray technology, delivering crisp monochrome graphics suitable for detailed information display in varying light conditions.
(2) Industrial-Grade Compatibility:
Fully interchangeable with Hitachi SP14N003 and LM7420 240×128 LCD panels, enabling seamless retrofits, upgrades, and maintenance for legacy systems.
(3) Rugged & Reliable Design:
ZEBRA Connection Technology: Ensures stable signal transmission and durable mechanical bonding for harsh environments.
MIL-STD Compliance: Passes rigorous tests (high/low temperature storage, vibration, ESD), meeting military-standard durability for industrial use.
(4) Flexible Power & Backlight Options:
Logic Supply: +5V (4.75–5.25V) with LED/CCFL-compatible backlight at +6V.
cCustomizable Displays: Choose black font on yellow-green LED, white font on blue background (white LED), or black font on gray background (white LED) for optimal visibility in any setting.
(5) Advanced Driver Technology:
LC7981/HD61830 driver IC supports 1/128 duty ratio and 1/12 bias, ensuring low power consumption and stable performance across temperatures (VOP voltage adjusts with temperature: 16.9V at 0°C, 15.8V at 25°C).
(6) Wide Temperature Performance:
Operates reliably at -20°C~70°C (storage: -30°C~80°C), ideal for outdoor, industrial, and extreme-environment applications.
(7) Easy System Integration:
8-bit data bus interface and standardized dimensions (PCB: 159.4×101.0×11.0mm) simplify integration into embedded systems, control panels, and retrofitted equipment.
2. Product technical parameters
| Keywords: |
5.5-inch monochrome LCD screen |
| Resolution: |
240×128 Pixels |
| LCD Size: |
159.4x101.0x13.2mm |
| Visual Area: |
124.0x70.0mm |
| Control driver: |
LC7981 |
| Surface Luminance: |
500cd/m2 |
| Operating Temp: |
-20℃～＋70℃ |
| Storage Temp: |
-30℃～＋80℃ |
| Display Type: |
STN/FSTN |
| Driving voltage: |
5.0V |
| LED Lifetime: |
40,000 Hours |
| Backlight: |
LED white light |
| Display Color: |
BLUE |
| Certificate: |
GB/T19001-2016/IS09001:2015 |
| Compliance: |
REACH & RoHS Compliant |
3. Product in details:
PS: This 5.5-inch 240×128 PixelsGraphic LCD Display is available for order with standard parameters. We also offer 240×128 Pixels Monochrome LCD Module in various specifications to meet different customer needs.If you need other sizes or customized products, you can also contact us and provide relevant drawings. We accept customized services and OEM processing.
4. Application fields
Here are the recommended application areas for the Graphic LCD Display:
Industrial Control Panels & Instrumentation
- Medical Devices & Healthcare Monitors
- Smart Home/Smart Building Control Systems
- Embedded Systems & IoT Devices
- Handheld Equipment & Portable Electronics
- Automotive Dashboards & Vehicle Displays
- Consumer Electronics (e.g., appliances, POS machines)
