Custom 16x2 Character LCD Module With Multi-Color Backlight 6800 Interface Wide Viewing Angle VATN Display
1. Definition
A Character LCD (Liquid Crystal Display) module is a display device designed to show alphanumeric characters, symbols, and simple icons. It uses predefined character patterns stored in its memory to form text-based information, typically arranged in rows and columns. Unlike graphic LCDs, character LCDs focus on presenting text rather than complex images or graphics.
2.Product Features and advantages
(1) Diverse Size Options:
Available in multiple alphanumeric configurations (8x2, 16x1, 16x2, 16x4, 20x2, 20x4, 40x4) to suit various display requirements, from compact to extended text applications.
(2) Vibrant Backlight Choices:
Offers a wide range of backlight colors, including white, blue, yellow-green, red, green, and amber, ensuring high visibility in different environments and aesthetic preferences.
(3) Flexible Interfaces:
Supports 6800, SPI, and I2C interfaces, providing seamless integration with diverse microcontrollers and systems to meet customized customer needs.
(4)Superior VATN Technology:
Features VATN displays with wide viewing angles and high contrast, enhancing readability and making them ideal for applications requiring optimal visibility from various perspectives.
(5) Standard 16-PIN Design:
The 16-pin configuration (e.g., 16x2 models) ensures compatibility with common setups, while select models (like 16x2) offer blue or yellow-green display colors for additional versatility.
(6) High Compatibility & Reliability:
Designed for easy integration and durability, suitable for industrial, consumer electronics, and embedded systems across different industries.
3. Product technical parameters
| Keywords: |
1.5inch Dot matrix LCD with monochrome characters |
| Resolution: |
16×2 Pixels |
| LCD Size: |
80.0x36.0x12.0mm |
| Visual Area: |
64.5x13.8mm |
| Control driver: |
ST7066U |
| Surface Luminance: |
100cd/m2 |
| Operating Temp: |
-20℃～＋70℃ |
| Storage Temp: |
-30℃～＋80℃ |
| Display Type: |
yellow green/STN |
| Driving voltage: |
5.0V |
| LED Lifetime: |
40,000 Hours |
| Backlight: |
LED white, blue, yellow, red, green and amber |
| Display Color: |
blue/yellowish green |
| Certificate: |
GB/T19001-2016/IS09001:2015 |
| Compliance: |
REACH & RoHS Compliant |
4. Product in details:
PS: This 16-character, 2-line Character Control Boards support customized,you can ask us for a complete data sheet and engineer technical support, at the same time, we have different specifications parameters of the 16*2LCD,Have any customize requirements, please feel free to Contact Us.
