Custom 7.0-Inch Industrial TFT LCD Module lcd monitor with WXGA 550cd/m² IP65-Ready for Harsh Environments
1. Product Features &Advantages
(1) High-Resolution Visuals:
7.0-inch WXGA (1024×600) display with 16.7M colors (8-bit grayscale) for vivid, detailed imagery, ideal for industrial data visualization.
550cd/m² brightness and 800:1 contrast ratio ensure clarity in bright/dim environments (e.g., factory floors, outdoor kiosks).
(2) Full-Viewing Angle Design:
85° horizontal/vertical viewing angles maintain consistent color/contrast from all orientations, perfect for shared or multi-user industrial interfaces.
(3) Environmental Resilience:
Operates in -10°C to 60°C (working) and -20°C to 70°C (storage), with resistance to high humidity (60°C/90%RH) and thermal shock. Built for harsh industrial, outdoor, or mobile applications (e.g., machinery, transportation systems).
(4) Flexible Connectivity:
TTL interface (44-pin) supports 24-bit RGB data, sync signals (HS/VS), and DE mode, enabling seamless integration with industrial control systems, embedded boards, or HMI platforms.
(5) Durable & Eco-Friendly Design:
Anti-glare (AG) surface reduces reflections for readability in hard light; RoHS-compliant materials meet environmental standards.
(6) Optional Capacitive Touchscreen (CTP):
Add precise multi-touch interactivity (resistant to industrial wear/tear) for HMI applications (e.g., machine control panels, IoT dashboards).
(7) Long-Lasting Performance:
40,000-hour backlight lifespan ensures sustained operation in 24/7 industrial settings, reducing maintenance costs.
(8) Certified and Compliant:
It is certified to GB/T19001 - 2016/IS09001:2015 and compliant with REACH and RoHS, which assures quality and environmental friendliness.
2. Product technical parameters
| Keywords: |
7-inch TFT color LCD |
| Resolution: |
1024×600 Pixels |
| LCD Interface: |
RGB |
| LCD Size: |
164.86X99.96X3.5mm |
| Visual Area: |
154.21X85.92mm |
| Control driver: |
TBD |
| Surface Luminance: |
350cd/m2 |
| Touch Screen: |
selectable |
| Operating Temp: |
-10℃～＋60℃ |
| Storage Temp: |
-30℃～＋80℃ |
| Display Type: |
IPS |
| Driving voltage: |
3.3V |
| LED Lifetime: |
40,000 Hours |
| Backlight: |
LED white light |
| Certificate: |
GB/T19001-2016/IS09001:2015 |
| Compliance: |
REACH & RoHS Compliant |
4. Product in details:
PS: This 7.0 -inch Industrial LCD Display is available for order with Standard parameters. we have different specifications parameters of the 7.0-inch Industrial LCD screen,If you need other sizes or customized products, please feel free to Contact Us and provide relevant drawings. We accept customized services and OEM processing.
4. Application fields
Industrial Automation: Machine operation panels, PLC interfaces, real-time data dashboards (e.g., manufacturing, robotics).
HMI (Human-Machine Interface): Rugged touchscreen controls for industrial equipment, kiosks, or vehicle-mounted systems.
Outdoor/Harsh Environments: Digital signage, outdoor monitors, or portable industrial devices (e.g., field diagnostics, construction machinery).
Transportation: In-vehicle displays for logistics, fleet management, or heavy-duty vehicle cockpits (resistant to temperature fluctuations/shock).
Energy & Utilities: Monitoring panels for power grids, renewable energy systems, or oil/gas infrastructure (high humidity/temp tolerance).
Why Choose JUNXian?
Founded in 2005, Junxian is a leading LCD display manufacturer. Our team of seasoned engineers and professionals offers a comprehensive range of LCD products. We also provide customized solutions for LCDs and touchscreens tailored to your unique needs.
1. Direct source factory, professional team, and competitive prices
Our own factory ensures both the product quality and production speed,We can provide quick prototyping to speed up your product development process. Our technical support team is always ready to assist you, ensuring a smooth experience from design to implementation.
2. Custom LCD Displays & CTP-Integrated Modules
With 20 years of manufacturing excellence, we specialize in crafting custom LCD displays—ranging from 0.96" to 15.6"—including models with fully integrated capacitive touch panels (CTP). Our professional capabilities enable end-to-end customization of critical components: FPC cables, backlight materials, PCBA board and display mode,ect;ensuring seamless alignment with your technical specifications.
3.Stringent Quality Control
Robust quality control processes at every stage—from raw materials to final inspection—guarantee superior performance and durability.
4. Certificates and Honors
We hold the GB/T19001 - 2016/IS09001:2015 certificate, ensuring that the quality of every product exceeds industry standards.
5. Rapid Delivery & Global Service
Streamlined workflows and flexible production enable quick order turnaround, supported by a worldwide logistics network.
With 20 years of expertise, we're not just suppliers! JUN Xian is your partners in innovation.
Contact us now to get custom LCD solutions, quick samples, and expert support, and let’s bring your vision to life!
Please Note
All photos on this site are authentic. However, due to variations in lighting, shooting angles, and display resolutions, slight chromatic aberration may occur. Thank you for your understanding.
We support product Customized Service and OEM& ODM service. Please contact our professional customer service team before placing an order to confirm product specification in details.
